Tractor · 1974Unverified
Valmet 702S
Valmet 702S — 02 Series · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
4040 kg
Hover a source tag to verify
Overview
ManufacturerValmetReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Power steeringReference
Cab standard with heater.Reference
Engine
Valmet 4.2L 4-cyl dieselReference
Fuel tank68.1 LReference
Engine55.9 kWReference
Valmet 411 BS 72Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke108 x 114 mmReference
Power55.9 kWReference
Rated RPM2200Reference
Torque261.8 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchromeshReference
16-speed two-speed power shiftReference
TypesynchromeshReference
Gears8 forward and 2 reverseReference
Clutch310mm dry discReference
Four gears (1-4) plus reverse (R) in two ranges (low/high).Reference
TransmissionHi-TracReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Pump flow26.1 lpmReference
Rear lift2120 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Engine RPM540@1556Reference
Engine RPM1000@2143Reference
Dimensions
Wheelbase224 cmReference
Weight4040 kgReference
Front tire7.50-18Reference
Rear tire13.6-38Reference
Ag front7.50-18Reference
Ag front13.6-28 (4WD)Reference
Ag rear13.6-38Reference
Ag rear18.4-34 (4WD)Reference
Length382 cmReference
Width199 cmReference
Height249 cmReference
Height (exhaust)256 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
