The Valpadana 1020 is a tractor model with an engine rating of approximately 16 hp, categorising it as a lighter model in its class. It is powered by a 2-cylinder, air-cooled petrol engine and features a hydrostatic transmission. The tractor's operating weight is listed at 310 kg, and it is suited for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
310 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
16 hp
Recorded weight
310 kg
Transmissions
Hydrostatic
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerValpadanaReference
Built in San Martino, ItalyReference
Steeringmechanical rackReference
Engine
0.5L 2-cyl gasolineReference
Engine11.9 kWReference
VanguardReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement0.5 LReference
Power11.9 kWReference
Air cleanerdryReference
Starter volts12Reference
PTO & Hydraulics
Rear lift299 kgReference
Front HitchoptionalReference
Front lift200 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOstandardReference
Mid PTO Type1500Reference
Front PTOoptionalReference
Front PTO Type1500Reference
Dimensions
Wheelbase108 cmReference
Weight310 kgReference
Front tire4.00-8Reference
Rear tire6.5/80-12Reference
Ag front4.00-8Reference
Ag rear6.5/80-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x8.50-12Reference
Length109 cmReference
Width76 cmReference
Height104 cmReference
Ground clearance18 cmReference
Electrical
Charging amps14Reference
Battery volts12Reference
Transmission
TransmissionHydrostaticReference
Gearsinfinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
