Tractor · Unverified
Valpadana 1540
Valpadana 1540 · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1599 kg
Hover a source tag to verify
Overview
ManufacturerValpadanaReference
Built in San Martino, ItalyReference
Four-wheel driveReference
Wet disc brakesReference
cab with heat optionalReference
Engine
1.6L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine26.5 kWReference
3TNV88-KLANReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 90 mmReference
Power26.5 kWReference
Air cleanerdryReference
Rated RPM2800Reference
Torque108.5 NmReference
Torque RPM1200Reference
Transmission
12-speedReference
16-speedReference
TransmissionshuttleReference
Gears12 forward and reverseReference
Transmissionshuttle/creeperReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)23.9 kWReference
Pressure110.0 barReference
Valves2 rear standardReference
Valves3 rear + 1 front optionalReference
Pump flow28.0 lpmReference
Total flow47.7 lpmReference
Steering flow19.7 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Front HitchIN optionalReference
Front lift399 kgReference
Rear PTO Type540/750Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase170 cmReference
Weight1599 kgReference
Front tire200/70-16Reference
Rear tire320/70-20Reference
Ag front200/70-16Reference
Ag rear320/70-20Reference
Length330 cmReference
Width129 cmReference
Height211 cmReference
Ground clearance34 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
