Tractor · Unverified

Valpadana 1545

Name: Valpadana 1545
Brand: Valpadana

Valpadana 1545 · 40 hp. Reference specifications; pending source verification.

The Valpadana 1545 is a tractor model with a rated power output of 40 hp, which positions it at the lighter end of its class. It is equipped with a 4-cylinder diesel liquid-cooled engine and features four-wheel drive with a 12-speed gearbox. The tractor's operating weight is listed as 1609 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1609 kg

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

40 hp

Recorded weight

1609 kg

Transmissions

12-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerValpadanaReference

Built in San Martino, ItalyReference

Four-wheel driveReference

Wet disc brakesReference

cab with heat and air conditining optionalReference

Engine

2.0L 4-cyl dieselReference

Fuel tank40.1 LReference

Engine32.8 kWReference

4TNV84-KLANReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke84 x 90 mmReference

Power32.8 kWReference

Air cleanerdryReference

Rated RPM2800Reference

Torque129.1 NmReference

Torque RPM1400Reference

Transmission

12-speedReference

16-speedReference

TransmissionshuttleReference

Gears12 forward and reverseReference

Transmissionshuttle/creeperReference

Gears16 forward and reverseReference

PTO & Hydraulics

PTO (claimed)29.8 kWReference

Pressure110.0 barReference

Valves2 rear standardReference

Valves3 rear + 1 front optionalReference

Pump flow28.0 lpmReference

Total flow47.7 lpmReference

Steering flow19.7 lpmReference

Rear TypeIReference

Rear lift1200 kgReference

Front HitchIN optionalReference

Front lift399 kgReference

Rear PTO Type540/750Reference

Front PTOoptionalReference

Front PTO Type1000Reference

Dimensions

Wheelbase170 cmReference

Weight1609 kgReference

Front tire240/70-16Reference

Rear tire360/70-20Reference

Ag front240/70-16Reference

Ag rear360/70-20Reference

Length330 cmReference

Width138 cmReference

Height214 cmReference

Ground clearance37 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
