Tractor · Unverified
Valpadana 1550
Valpadana 1550 · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
1609 kg
Hover a source tag to verify
Overview
ManufacturerValpadanaReference
Built in San Martino, ItalyReference
Four-wheel driveReference
Wet disc brakesReference
cab with heat and air conditining optionalReference
Engine
2.2L 4-cyl dieselReference
Fuel tank40.1 LReference
Engine35.4 kWReference
4TNV88-KLANReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke88 x 90 mmReference
Power35.4 kWReference
Air cleanerdryReference
Rated RPM2800Reference
Torque141.0 NmReference
Torque RPM1200Reference
Transmission
12-speedReference
16-speedReference
TransmissionshuttleReference
Gears12 forward and reverseReference
Transmissionshuttle/creeperReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)32.1 kWReference
Pressure110.0 barReference
Valves2 rear standardReference
Valves3 rear + 1 front optionalReference
Pump flow28.0 lpmReference
Total flow47.7 lpmReference
Steering flow19.7 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Front HitchIN optionalReference
Front lift399 kgReference
Rear PTO Type540/750Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase170 cmReference
Weight1609 kgReference
Front tire240/70-16Reference
Rear tire360/70-20Reference
Ag front240/70-16Reference
Ag rear360/70-20Reference
Length330 cmReference
Width138 cmReference
Height214 cmReference
Ground clearance37 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
