Tractor · Unverified
Valpadana 1645
Valpadana 1645 · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Weight
1579 kg
Hover a source tag to verify
Overview
ManufacturerValpadanaReference
Built in San Martino, ItalyReference
Four-wheel driveReference
Wet disc brakesReference
cab with heat and air conditining optionalReference
Engine
2.0L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine32.8 kWReference
4TNE84-ELANReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke84 x 90 mmReference
Power32.8 kWReference
Air cleanerdryReference
Rated RPM2800Reference
Torque120.0 NmReference
Torque RPM1600Reference
Transmission
12-speedReference
16-speedReference
TransmissionshuttleReference
Gears12 forward and reverseReference
Transmissionshuttle/creeperReference
Gears16 forward and reverseReference
TransmissionhydrostaticReference
Gearsinfinite 3-range forward and reverseReference
PTO & Hydraulics
PTO (claimed)26.8 kWReference
Valves3 rearReference
Valves1 front optionalReference
Pump flow28.0 lpmReference
Total flow47.7 lpmReference
Steering flow19.7 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Front HitchI optionalReference
Front lift399 kgReference
Rear PTO Type540/750/groundReference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase181 cmReference
Weight1579 kgReference
Front tire240/70-16Reference
Rear tire360/70-20Reference
Ag front240/70-16Reference
Ag rear360/70-20Reference
Length341 cmReference
Width137 cmReference
Height233 cmReference
Ground clearance37 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
