Tractor · Unverified
Valpadana 3660
Valpadana 3660 · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
5512 to 6184 pounds
Hover a source tag to verify
Overview
ManufacturerValpadanaReference
Built in San Martino, ItalyReference
Four-wheel driveReference
Wet disc brakesReference
cab with heat optionalReference
Variants
FNarrow for orchards and vineyardsReference
GElow-clearanceReference
Engine
3.3L 3-cyl dieselReference
Engine43.8 kWReference
1103C-33Reference
dieselReference
3-cylinderReference
Displacement3.3 LReference
Power43.8 kWReference
Torque222.0 NmReference
Transmission
15-speedReference
30-speedReference
40-speedReference
Transmissionsync shuttleReference
Gears15 forward and reverseReference
Gears30 forward and reverseReference
Transmissionpower shuttleReference
Gears40 forward and reverseReference
PTO & Hydraulics
PTO (claimed)40.3 kWReference
Valves2Reference
Pump flow52.2 lpmReference
Total flow82.1 lpmReference
Steering flow29.9 lpmReference
Rear TypeIIReference
Rear lift2600 kgReference
Rear PTO Type540/750/groundReference
Rear PTO Type1000 optionalReference
Dimensions
Wheelbase201 cmReference
Weight5512 to 6184 poundsReference
Length389 cmReference
Width132 cmReference
Width143 cmReference
Height225 cmReference
Height215 cmReference
Weight2805 kgReference
Weight2500 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
