Tractor · 1999Unverified

Valpadana 9565

Name: Valpadana 9565
Brand: Valpadana

Valpadana 9565 — Orchard/Vineyard tractor · 64 hp. Reference specifications; pending source verification.

The Valpadana 9565 is a tractor with a rated power output of approximately 64 hp, positioning it at the lower end of its class. Manufactured from 1999 to 2001, it features a 4-cylinder diesel air-cooled engine, coupled with four-wheel drive and a 36-speed gearbox. The operating weight of the Valpadana 9565 ranges from 4409 to 4630 pounds. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

64 hp

Weight

4409 to 4630 pounds

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

64 hp

Recorded weight

2100 kg

Transmissions

36-speed mechanical shuttle

Production years

1999-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerValpadana (a part of Argo)Reference

Orchard/Vineyard tractorReference

Drive4x4 4WDReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post mid-mount folding ROPS or four-post ROPS. Reversible operator station.Reference

Engine

Deutz 2.7L 4-cyl dieselReference

Fuel tank50.0 LReference

Engine47.8 kWReference

DeutzReference

dieselReference

4-cylinderReference

air-cooledReference

Displacement2.7 LReference

Bore/Stroke91 x 105 mmReference

Power47.8 kWReference

Compression18.5:1Reference

Rated RPM2650Reference

StarterelectricReference

Starter volts12Reference

Transmission

36-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears36 forward and reverseReference

Clutch250mm dry discReference

PTO & Hydraulics

Valves3Reference

Total flow50.0 lpmReference

Rear TypeIIReference

Controlposition controlReference

Rear lift1500 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Multitrac Wheelbase152 cmReference

Climber Wheelbase157 cmReference

Weight4409 to 4630 poundsReference

Front tire320/70-20Reference

Multitrac Rear tire320/70-20Reference

Multitrac Standard tires (ag)Front: 320/70-20. Rear: 320/70-20Reference

Climber Standard tires (ag)Front: 31x15.50-15STG1. Rear: 31x15.50-15STG1Reference

Optional tires (ag)Front: 300/70-20. Rear: 300/70-20Reference

Optional tires (ag)Front: 360/70-20. Rear: 360/70-20Reference

Optional tires (ag)Front: 400/55-17.5T404. Rear:Reference

Optional tires (ag)Front: 400/55-22.5T404. Rear:Reference

Optional tires (ag)Front: 33x15.50-15T412. Rear:Reference

Length350 cmReference

Multitrac Width146 cmReference

Climber Width183 cmReference

Height (ROPS)211 cmReference

Height (ROPS)234 cmReference

Multitrac Weight2100 kgReference

Climber Weight1999 kgReference

Multitrac Front tread115 to 133 cmReference

Climber Front tread144 cmReference

Multitrac Rear tread115 to 133 cmReference

Climber Rear tread144 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
