Tractor · 2004Unverified
Valtra 3100
Valtra 3100 — Compact Utility tractor · 52 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
5159 to 5644 pounds
Hover a source tag to verify
Overview
ManufacturerValtraReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab optional with heat and A/CReference
Variants
3100Ccompact tractorReference
3100Fnarrow orchard tractorReference
Engine
Deutz 2.8L 3-cyl dieselReference
Fuel tank60.2 LReference
Engine38.8 kWReference
Deutz F3L912Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 120 mmReference
Power38.8 kWReference
Rated RPM2350Reference
Torque170.0 NmReference
Torque RPM1600Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed partially synchronizedReference
Typepartially synchronizedReference
Gears24 forward and reverseReference
Four synchronized gears in three ranges with splitter.Reference
PTO & Hydraulics
Valves1 to 4Reference
Pump flow26.9 lpmReference
Steering flow20.1 lpmReference
Rear PTO Typeground/540/540EReference
Rear PTO Typeground/540/1000Reference
Dimensions
Wheelbase209 cmReference
Weight5159 to 5644 poundsReference
Front tire9.5R20Reference
Rear tire13.6R28Reference
Ag front9.5R20Reference
Ag rear13.6R28Reference
Ag front10.0/75-15.3 (orchard)Reference
Ag rear360/70-24 (orchard)Reference
Length375 cmReference
Width169 cmReference
Width132 cmReference
Height (ROPS)257 cmReference
Height (cab)231 cmReference
ROPS Weight2340 kgReference
Cab Weight2560 kgReference
Ground clearance35 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
