Tractor · 2017Unverified

Valtra A104

Valtra A104 — A Series · 97 hp. Reference specifications; pending source verification.

The Valtra A104 is a tractor with a rated power output of 97 hp, a mid-range figure for its class. It was manufactured from 2017 to 2020. The tractor features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. Its listed operating weight is 3999 kg, and it is suitable for operations of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
97 hp
Max power
97 hp
Weight
3999 kg

Catalogue coverage

Variants represented
2
Richest spec table
70 rows
Recorded power
97 hp
Recorded weight
3999 kg
Transmissions
12-speed power shuttle
Production years
2017-2020
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerValtra (a part of AGCO)Reference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with available air-conditioning.Reference

Engine

AGCO Power 4.4L 4-cyl dieselReference
Fuel tank149.9 LReference
Exhaust fluid (DEF)20.1 LReference
Engine72.3 kWReference
AGCO Power 44 AWFCReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
Power72.3 kWReference
Maximum Power74.6 kWReference
Torque409.5 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Fuel TypeDieselReference
No of Cylinders4 cylinderReference
Engine torque at rated speed137 kgReference
Bore and stroke4.25x4.72 inchesReference
Cooling systemliquid-cooledReference

Transmission

12-speed power shuttleReference
16-speed four-speed power shiftReference
Typepower shuttleReference
Gears12 forward and reverseReference
TransmissionHiTech4Reference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Transmission TypePower ShuttleReference
forward and reverse optionsPowershuttle; 12 F & 12 R | HiTech4; 16 F &16 RReference
Wheel Drive4WDReference

PTO & Hydraulics

Typeopen centerReference
Pump flow98.0 lpmReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E/1000Reference
Engine RPM540@1920Reference
Engine RPM540E@1560Reference

Dimensions

Wheelbase243 cmReference
Weight3999 kgReference
Length435 cmReference
Height (cab)271 cmReference
Clearance (front axle)43 cmReference
Operating3999 kgReference
Max front axle3499 kgReference
Max rear axle6400 kgReference

Electrical

GroundnegativeReference
Battery volts12Reference

Capacities

Max capacity8500 kgReference
Capacity268.5 ciReference
Diesel exhaust fluid (DEF) tank20.1 LReference

Power

Max Power97 hpReference

PTO

Rear PTO PowerAvailableReference
Rear PTO RPM1,000 RPMReference
Engine Speed on Rear PTO speed540@1,920rpm | 540E@1,560rpmReference

Steering & brakes

Brakeswet discReference
Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

General

SCV controlJoystickReference

Dimensions & weight

Front axle clearance43.7 cmReference
Overall weight3,999.8 kgReference

Operator station

Cab AvailabilityavailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
