Tractor · 2021Unverified

Valtra A105

Name: Valtra A105
Brand: Valtra

Valtra A105 — A Series · 105 hp. Reference specifications; pending source verification.

The Valtra A105 is a tractor model with an engine rating of approximately 105 horsepower, a typical power output for its category. It was produced in 2021. It features a 4-cylinder turbocharged intercooled diesel engine with liquid cooling, paired with a four-wheel drive system and a powershift transmission. The A105 is suitable for operations covering areas of 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

105 hp

Max power

105 hp

Weight

8,500 kg (Maximum permissible weight)

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

105 hp

Transmissions

16-speed four-speed power shift

Production years

2021-2021

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerValtra (a part of AGCO)Reference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard with available air-conditioning.Reference

Engine

AGCO Power 4.4L 4-cyl dieselReference

AGCO Power 44 AWFCReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke108 x 120 mmReference

EmissionsStage 5Reference

Maximum Power78.3 kWReference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4Reference

Rated engine speed2,200 rpmReference

Emissions complianceStage VReference

Transmission

16-speed four-speed power shiftReference

TransmissionHiTech4Reference

Typefour-speed power shiftReference

Gears16 forward and reverseReference

Transmission TypePower ShuttleReference

forward and reverse options16x16Reference

forward speed range0-40 kmhReference

Wheel Drive4WDReference

Electrical

GroundnegativeReference

Battery volts12Reference

Capacities

Capacity4.4 LReference

Fuel tank175 LReference

Diesel exhaust fluid (DEF) tank13 LReference

Power

Max Power105 hpReference

PTO

Rear PTO PowerYesReference

Rear PTO RPM1,000 rpmReference

Engine Speed on Rear PTO speed1,000Reference

Hydraulics

Pump Rated Output (total)98 l/minReference

Hydraulics TypeOpen CenterReference

Number of rear selective control valves (SCVs)2 or 3Reference

General

SCV controlJoystickReference

Dimensions & weight

Wheelbase2,430 mmReference

Overall Height2,799 mmReference

Overall Length4,376 mmReference

Overall Width2,250 mmReference

Ground Clearance428 mmReference

Turning radius4.04 m (without Brakes)Reference

Overall weight4,305 kgReference

Weight8,500 kg (Maximum permissible weight)Reference

Operator station

Cab AvailabilityTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
