Tractor · 2017Unverified

Valtra A124

Name: Valtra A124
Brand: Valtra

Valtra A124 — A Series · 117 hp. Reference specifications; pending source verification.

The Valtra A124 is a tractor model with an engine rating of 117 hp, placing it in the middle of its class for power. It was produced from 2017 to 2020, and is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine. This engine is connected to a 12-speed gearbox and powers four-wheel drive. The model has a listed weight of 4500 kg and is suitable for jobs that typically require 200–800 acres of land to be managed.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

117 hp

Max power

117 hp

Weight

4500 kg

Catalogue coverage

Variants represented

Richest spec table

70 rows

Recorded power

117 hp

Recorded weight

4500 kg

Transmissions

12-speed power shuttle

Production years

2017-2020

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerValtra (a part of AGCO)Reference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard with available air-conditioning.Reference

Engine

AGCO Power 4.4L 4-cyl dieselReference

Fuel tank180.2 LReference

Exhaust fluid (DEF)20.1 LReference

Engine87.2 kWReference

AGCO Power 44 AWFCReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke108 x 120 mmReference

Power87.2 kWReference

Maximum Power89.5 kWReference

Torque509.9 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4 cylinderReference

Engine torque at rated speed170.6 kgReference

Bore and stroke4.25x4.72 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed power shuttleReference

24-speed creeperReference

Typepower shuttleReference

Gears12 forward and reverseReference

TypecreeperReference

Gears24 forward and reverseReference

Transmission TypePower ShuttleReference

forward and reverse optionsPowershuttle; 12 F & 12R | Creeper; 24 F &24 RReference

Wheel Drive4WDReference

PTO & Hydraulics

Typeopen centerReference

Pump flow98.0 lpmReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Rear PTO Type540/540E/1000Reference

Engine RPM540@1920Reference

Engine RPM540E@1560Reference

Dimensions

Wheelbase249 cmReference

Weight4500 kgReference

Length438 cmReference

Height (cab)271 cmReference

Clearance (front axle)43 cmReference

Operating4500 kgReference

Max front axle3499 kgReference

Max rear axle6400 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Capacities

Max capacity8500 kgReference

Capacity268.5 ciReference

Diesel exhaust fluid (DEF) tank20.1 LReference

General

Make & ModelValtra (a part of AGCO)Reference

SCV controlJoystickReference

Power

Max Power117 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Engine Speed on Rear PTO speed540@1,920rpm | 540E@1,560rpmReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Dimensions & weight

Front axle clearance43.7 cmReference

Overall weight4,500.1 kgReference

Operator station

Cab AvailabilityavailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
