Tractor · 2001Unverified

Valtra S230

Name: Valtra S230
Brand: Valtra

Valtra S230 — S Series · 227 hp. Reference specifications; pending source verification.

The Valtra S230 is a tractor with a rated output of 227 hp, categorising it among the higher-powered models in its class. It was manufactured from 2001 to 2003. The tractor is equipped with a 6-cylinder turbocharged, intercooled diesel, liquid-cooled engine that powers a four-wheel drive system with a powershift transmission. Its listed weight is 8800 kg, and it is designed for tasks covering approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

227 hp

Weight

8800 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

227 hp

Recorded weight

8800 kg

Transmissions

40-speed four-speed power shift

Production years

2001-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerValtraReference

Row-Crop tractorReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

SisuDiesel 8.4L 6-cyl dieselReference

Fuel tank599.9 LReference

Engine169.3 kWReference

SisuDiesel 645 ESBAEReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement8.4 LReference

Bore/Stroke111 x 145 mmReference

Power169.3 kWReference

Rated RPM2200Reference

Torque950.6 NmReference

Torque RPM1400Reference

Starter typeelectricReference

Transmission

40-speed four-speed power shiftReference

Typefour-speed power shiftReference

Gears40 forward and reverseReference

PTO & Hydraulics

Typeclosed centerReference

Pressure200.0 barReference

Pump flow146.9 lpmReference

Rear lift10196 kgReference

Front lift7494 kgReference

Rear PTOindependentReference

Rear PTO Type1000Reference

Engine RPM1000@2112Reference

Front PTOindependentReference

Front PTO Type1000Reference

Engine RPM1000@2071Reference

Dimensions

Wheelbase308 cmReference

Wheelbase310 cmReference

Weight8800 kgReference

Front tire480/65R30Reference

Rear tire520/85R42Reference

Standard tires (ag)Front: 480/65R30. Rear: 520/85R42Reference

Length510 cmReference

Width249 cmReference

Height (cab)340 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
