Tractor · 2003Unverified
Valtra S240
Valtra S240 — S Series · 243 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
243 hp
Weight
8799 kg
Hover a source tag to verify
Overview
ManufacturerValtraReference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standardReference
Engine
SisuDiesel 8.4L 6-cyl dieselReference
Fuel tank599.9 LReference
Engine181.2 kWReference
SisuDiesel 84ETAReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.4 LReference
Bore/Stroke111 x 145 mmReference
Power181.2 kWReference
Rated RPM2200Reference
Torque969.5 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
40-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears40 forward and reverseReference
PTO & Hydraulics
Typeclosed centerReference
Pressure200.0 barReference
Valves7Reference
Pump flow146.9 lpmReference
Rear lift10196 kgReference
Front lift7493 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Engine RPM1000@21112Reference
Front PTOindependentReference
Front PTO Type1000Reference
Engine RPM1000@2071Reference
Dimensions
Wheelbase308 cmReference
Wheelbase310 cmReference
Weight8799 kgReference
Front tire480/65R30Reference
Rear tire520/85R42Reference
Ag front480/65R30Reference
Ag rear520/85R42Reference
Length510 cmReference
Width249 cmReference
Height (cab)340 cmReference
Clearance (front axle)56 cmReference
Clearance (rear axle)52 cmReference
Electrical
GroundnegatveReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
