Tractor · 2012Unverified
Valtra T133
Valtra T133 — T 3 Series · 141 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
141 hp
Hover a source tag to verify
Overview
ManufacturerValtra (a part of AGCO)Reference
Row-Crop tractorReference
Built in Suolahti, FinlandReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
AGCO Power 6.6L 6-cyl dieselReference
HiTech Fuel tank165.0 LReference
HiTech Fuel tank335.0 LReference
Versu Fuel tank285.0 LReference
Versu Fuel tank375.1 LReference
Direct Fuel tank285.0 LReference
Direct Fuel tank375.1 LReference
Exhaust fluid (DEF)26.9 LReference
Engine (max)105.1 kWReference
Engine (boost)113.3 kWReference
AGCO Power 66 AWI-4VReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooled inlineReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
EmissionsStage IIIBReference
Maximum Power105.1 kWReference
Boost Power113.3 kWReference
Torque580.4 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
36-speed three-speed power shiftReference
TransmissionDeltaReference
Typethree-speed power shiftReference
Gears36 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Rear valves4Reference
Front valves2Reference
Pump flow73.1 lpmReference
Pump flow90.1 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540E@1539Reference
Engine RPM540@1874Reference
Engine RPM1000@2000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Engine RPM1000@1920Reference
Dimensions
Wheelbase274 cmReference
Front tire16.9R28Reference
Rear tire20.8R38Reference
Standard tires (ag)Front: 16.9R28. Rear: 20.8R38Reference
Length514 cmReference
Width228 cmReference
Height (cab)303 cmReference
Clearance (rear axle)59 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
