Tractor · 2009Unverified

Valtra T172

Name: Valtra T172
Brand: Valtra

Valtra T172 — T 2 Series · 170 hp. Reference specifications; pending source verification.

The Valtra T172 is a tractor rated at 170 hp, falling within the higher-powered category of its class. Manufactured between 2009 and 2011, this model features a 6-cylinder turbocharged diesel liquid-cooled engine. It is propelled by four-wheel drive via a continuously variable transmission. The listed weight of the Valtra T172 is 6090 kg, and it is designed for tasks involving approximately 600–1,500 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

170 hp

Weight

6090 kg

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

170 hp

Recorded weight

6090 kg

Transmissions

30-speed five-speed power shift

Production years

2009-2011

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerValtra (a part of AGCO)Reference

Row-Crop tractorReference

Built in Suolahti, FinlandReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

Versupower shiftReference

DirectCVTReference

Engine

SisuPower 6.6L 6-cyl dieselReference

Engine (gross)126.8 kWReference

Engine (max)132.0 kWReference

SisuPower 66 CTA-4VReference

turbocharged dieselReference

6-cylinder 24-valveReference

liquid-cooled inlineReference

Displacement6.6 LReference

Bore/Stroke108 x 120 mmReference

Rated Power (gross)126.8 kWReference

Maximum Power (gross)132.0 kWReference

Maximum Power (gross)137.2 kWReference

Rated RPM2200Reference

Torque714.6 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

30-speed five-speed power shiftReference

continuously-variable transmissionReference

TransmissionVersuReference

Typefive-speed power shiftReference

Gears30 forward and reverseReference

Clutchwet discReference

Five power shift gears in six ranges with power shuttle.Reference

TransmissionNordic CVTReference

Typecontinuously-variable transmissionReference

Gearsinfinite forward and reverseReference

Capacities

Fuel375.1 LReference

PTO & Hydraulics

Hydraulic system46.9 LReference

Typeload-sensingReference

Capacity46.9 LReference

Rear valves3 to 5Reference

Front valves3Reference

Pump flow115.1 lpmReference

Pump flow160.1 lpmReference

Rear TypeIIIReference

Rear lift8099 kgReference

Rear lift8500 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540E@1539Reference

Engine RPM540@1874Reference

Engine RPM1000@2000Reference

Dimensions

Wheelbase274 cmReference

Weight6090 kgReference

Front tire540/65R30Reference

Rear tire650/65R42Reference

Standard tires (ag)Front: 540/65R30. Rear: 650/65R42Reference

Length514 cmReference

Width233 cmReference

Height (cab)304 cmReference

Clearance (rear axle)59 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
