Tractor · 2012Unverified
Valtra T183
Valtra T183 — T 3 Series · 188 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
188 hp
Hover a source tag to verify
Overview
ManufacturerValtra (a part of AGCO)Reference
Row-Crop tractorReference
Built in Suolahti, FinlandReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
AGCO Power 7.4L 6-cyl dieselReference
Fuel tank285.0 LReference
Fuel tank375.1 LReference
Exhaust fluid (DEF)26.9 LReference
Engine (max)140.2 kWReference
Engine (boost)149.9 kWReference
AGCO Power 74 AWI-4VReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooled inlineReference
Displacement7.4 LReference
Bore/Stroke108 x 134 mmReference
EmissionsStage IIIBReference
Maximum Power140.2 kWReference
Boost Power149.9 kWReference
Torque770.2 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
30-speed five-speed power shiftReference
continuously-variable transmissionReference
TransmissionVersuReference
Typefive-speed power shiftReference
Gears30 forward and reverseReference
Clutchwet discReference
TransmissionNordic CVTReference
Typecontinuously-variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typeclosed center load-sensingReference
Rear valves7Reference
Front valves3Reference
Pump flow115.1 lpmReference
Pump flow160.1 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540E@1539Reference
Engine RPM540@1874Reference
Engine RPM1000@2000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Engine RPM1000@1920Reference
Dimensions
Wheelbase274 cmReference
Front tire480/70R30Reference
Rear tire620/70R42Reference
Standard tires (ag)Front: 480/70R30. Rear: 620/70R42Reference
Length514 cmReference
Width233 cmReference
Height (cab)304 cmReference
Clearance (rear axle)59 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
