Tractor · 2012Unverified

Valtra T193

Valtra T193 — T 3 Series · 190 hp. Reference specifications; pending source verification.

The Valtra T193 is a tractor with a rating of 190 hp, positioning it in the higher-powered segment of its class. The T193 was produced between 2012 and 2015. It features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with a powershift transmission and four-wheel drive. This model is suitable for applications covering around 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
190 hp

Catalogue coverage

Variants represented
2
Richest spec table
63 rows
Recorded power
190 hp
Transmissions
36-speed three-speed power shift
Production years
2012-2015
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerValtra (a part of AGCO)Reference
Row-Crop tractorReference
Built in Suolahti, FinlandReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference

Engine

AGCO Power 7.4L 6-cyl dieselReference
HiTech Fuel tank165.0 LReference
HiTech Fuel tank335.0 LReference
Versu Fuel tank285.0 LReference
Versu Fuel tank375.1 LReference
Direct Fuel tank285.0 LReference
Direct Fuel tank375.1 LReference
Exhaust fluid (DEF)26.9 LReference
Engine (max)141.7 kWReference
Engine (boost)156.6 kWReference
AGCO Power 74 AWI-4VReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooled inlineReference
Displacement7.4 LReference
Bore/Stroke108 x 134 mmReference
EmissionsStage IIIBReference
Maximum Power141.7 kWReference
Boost Power156.6 kWReference
Torque680.7 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference

Transmission

36-speed three-speed power shiftReference
TransmissionDeltaReference
Typethree-speed power shiftReference
Gears36 forward and reverseReference

PTO & Hydraulics

HiTech Typeopen centerReference
Versu Typeclosed center load-sensingReference
Direct Typeclosed center load-sensingReference
Rear valves7Reference
Front valves3Reference
Pump flow73.1 lpmReference
Pump flow90.1 lpmReference
Pump flow115.1 lpmReference
Pump flow160.1 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540E@1539Reference
Engine RPM540@1874Reference
Engine RPM1000@2000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Engine RPM1000@1920Reference

Dimensions

Wheelbase274 cmReference
Front tire480/70R30Reference
Rear tire620/70R42Reference
Standard tires (ag)Front: 480/70R30. Rear: 620/70R42Reference
Length514 cmReference
Width233 cmReference
Height (cab)304 cmReference
Clearance (rear axle)59 cmReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
