Lawn Tractor · 1999Unverified
Ventrac 3000
Ventrac 3000 · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
322 kg
Hover a source tag to verify
Overview
ManufacturerVentracReference
Built in Orrville, Ohio, USAReference
Four-wheel driveReference
Open operator station. Hard cab optional.Reference
Engine
21HP Kawasaki 675cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Kawasaki FH601VReference
gasolineReference
2-cylinder vertical-shaft V-Twin-valveReference
air-cooledReference
Displacement41.2 ciReference
Bore/Stroke72 x 76 mmReference
Power15.7 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-Gear GT-1700Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Wheelbase91 cmReference
Weight322 kgReference
Front tire18x10.50-10Reference
Rear tire18x10.50-10Reference
Lawn/turf front18x10.50-10Reference
Lawn/turf rear18x10.50-10Reference
Length182 cmReference
Width101 cmReference
Height121 cmReference
Ventrac 3000 attachments
front-mount mower deckReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging volts13Reference
Battery CCA560Reference
Battery volts12Reference
Mower deck
Typefront-mount VentracReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
