Tractor · 1981Unverified
Versatile 1150
Versatile 1150 — Four-wheel Drive (4WD) tractor · 470 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
470 hp
Hover a source tag to verify
Overview
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Original price$160,544 (1983 )Reference
Original price$187,000 (1985 )Reference
Four-wheel driveReference
Differential lockelectric front and rearReference
Disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 18.8L 6-cyl dieselReference
Fuel tank1514.0 LReference
Engine350.5 kWReference
Drawbar (claimed)298.3 kWReference
Cummins KTA 1150CReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement18.8 LReference
Bore/Stroke159 x 159 mmReference
Power350.5 kWReference
Rated RPM2100Reference
Coolant capacity80.4 LReference
Transmission
8-speed gearReference
12-speed power shiftReference
TypegearReference
Gears8 forward and 4 reverseReference
Clutch393.7mm cerametallic discReference
Typepower shiftReference
Gears12 forward and 2 reverseReference
PTO & Hydraulics
Typeclosed center load sensingReference
Valves5Reference
Rear PTO Type1000Reference
Dimensions
Wheelbase355 cmReference
Front tire20.8x38Reference
Rear tire20.8x38Reference
Ag front20.8x38Reference
Ag front20.8x42Reference
Ag front24.5x32Reference
Ag front30.5x32Reference
Ag rear20.8x38Reference
Ag rear20.8x42Reference
Ag rear24.5x32Reference
Ag rear30.5x32Reference
1150 Serial Numbers
Location:Serial number plate on the cab door post.Reference
19811150 81 201001Reference
19821150 82 201101Reference
19831150 83 204101Reference
19841150 84 204351Reference
19851150 85 237075Reference
Final1150 85 237225Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
