Tractor · 2014Unverified

Versatile 290

Name: Versatile 290
Brand: Versatile

Versatile 290 — Row-Crop tractor · 290 hp. Reference specifications; pending source verification.

The Versatile 290 is a tractor with a rated power output of 290 horsepower, positioning it towards the higher end of its class in terms of power. This model was manufactured from 2014 to 2017. It features a 6-cylinder turbocharged diesel liquid-cooled engine paired with four-wheel drive and a powershift transmission. The tractor's operating weight is listed as 10,861 kg, making it suitable for operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

290 hp

Max power

290 hp

Weight

10861 kg

Catalogue coverage

Variants represented

Richest spec table

91 rows

Recorded power

290 hp

Recorded weight

10861 kg

Transmissions

16-speed full power shift

Production years

2014-2017

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerVersatile (a part of Rostselmash)Reference

Row-Crop tractorReference

Built in Winnipeg, Manitoba, CanadaReference

Four-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Cab standard with air-conditioning.Reference

Engine

Cummins 8.9L 6-cyl dieselReference

Fuel tank643.5 LReference

Engine216.3 kWReference

Cummins QSL9Reference

turbocharged and air-to-air aftercooled dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement8.9 LReference

Bore/Stroke114 x 145 mmReference

EmissionsInterim Tier IVReference

Emission controlexhaust gas recirculation and diesel particulate filter (DPF) (EGR)Reference

Power216.3 kWReference

Maximum Power243.1 kWReference

Rated RPM2100Reference

Torque1335.7 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders6 cylinderReference

Rated engine speed2,100 RPMReference

Engine torque at rated speed446.8 kgReference

Bore and stroke4.49x5.69 inchesReference

Cooling systemliquid-cooled inlineReference

Transmission

16-speed full power shiftReference

Typefull power shiftReference

Gears16 forward and 9 reverseReference

Transmission TypePowershiftReference

forward and reverse options16 F and 9 RReference

Wheel Drive4WDReference

Rear Axle Drive Typeinboard planetaryReference

PTO & Hydraulics

Typeclosed center load sensing (CCLS)Reference

Pressure200.0 barReference

Valves4 to 6Reference

Pump flow208.2 lpmReference

Pump flow283.9 lpmReference

Rear TypeIII/IIINReference

Rear lift8550 kgReference

Rear PTOindependentReference

Rear PTO Type1000Reference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase316 cmReference

Weight10861 kgReference

Front tire420/90R30Reference

Rear tire480/80R46Reference

Ag front420/90R30Reference

Ag rear480/80R46Reference

Length640 cmReference

Height (cab)342 cmReference

Max weight13918 kgReference

Bar rear axle109 by 3048 mmReference

Front tread152 to 223 cmReference

Rear tread152 to 335 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps200Reference

Charging volts12Reference

Batteries2Reference

Battery CCA950Reference

Battery volts12Reference

Total cold cranking amps950 ampsReference

General

Make & ModelVersatile (a part of Rostselmash)Reference

Cruise controlAvailableReference

Rear Axle TypeBar - 4.3 by 120 inchesReference

Country of manufacturerCanadaReference

Capacities

Capacity543 ciReference

Power

Max Power290 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Hydraulics

Hydraulics Typeclosed center load sensing (CCLS)Reference

Maximum operating pressure2,900 psiReference

Remote Valves4 to 6Reference

Rear Hitch category (SAE designation)Category III/IIINReference

Rear Hitch maximum lift capacity8,550.2 kgReference

Dimensions & weight

Height Over Cab342.1 cmReference

Overall Length640.1 cmReference

Overall weight10,861.3 kgReference

Wheels & tyres

Rear Wheel Type480/80R46Reference

Rear wheel tread range60 to 132 inchesReference

Front Wheel Type420/90R30Reference

Front Wheel tread range60 to 88 inchesReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Steering & brakes

Steering typePowerReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
