Tractor · 2012Unverified
Versatile 305
Versatile 305 — Row-Crop tractor · 256 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
256 hp
Max power
234.4 kW
Weight
19150 to 20050 pounds
Hover a source tag to verify
Overview
ManufacturerVersatile (a part of Rostselmash)Reference
Row-Crop tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Cab standard with air-conditioning.Reference
Engine
Cummins 8.3L 6-cyl dieselReference
Engine227.4 kWReference
Drawbar (tested)157.0 kWReference
Cummins QSCReference
turbocharged and air-to-air aftercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
EmissionsTier IIIReference
Power227.4 kWReference
Rated RPM2100Reference
Torque1383.1 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity27.4 LReference
Max power234.4 kWReference
Power at rated engine speed190.7 kWReference
Max power157.0 kWReference
Transmission
16-speed full power shiftReference
Typefull power shiftReference
Gears16 forward and 9 reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
PTO (claimed)182.7 kWReference
PTO (tested)234.4 kWReference
Hydraulic system117.3 LReference
Typeclosed center load sensing (CCLS)Reference
Capacity117.3 LReference
Pressure200.0 barReference
Valves3 or 4Reference
Pump flow113.6 lpmReference
Pump flow208.2 lpmReference
Rear TypeIIIReference
Controlelectronic draft controlReference
Rear lift6804 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Rear PTO Type1000 (1.375 optional)Reference
Power at rated PTO speed234.0 kWReference
Capacities
Fuel416.4 LReference
Dimensions
Wheelbase307 cmReference
Wheelbase317 cmReference
Weight19150 to 20050 poundsReference
Length508 cmReference
Length508 cmReference
Height (cab)317 cmReference
Height (exhaust)320 cmReference
Weight8686 kgReference
Weight9094 kgReference
Ground clearance47 cmReference
Bar rear axle104 by 2844 mmReference
Bar rear axle104 by 3048 mmReference
Front tread152 to 223 cmReference
Rear tread152 to 314 cmReference
Rear tread152 to 335 cmReference
Versatile 305 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps160Reference
Charging amps180 (optional)Reference
Charging volts12Reference
Batteries2Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Versatile 3995 SL loaderReference
Test results
Diesel 16-speed 4WDJune 21 - 24, 2011Link: OCED Tractor Test 1997 fileReference
PTO performanceReference
Fuel use67.8 l/hourReference
Fuel use61.3 l/hourReference
Fuel use67.0 l/hourReference
Drawbar performanceReference
Fuel use61.7 l/hourReference
Gear 7 used for power test.Reference
Max pull8780 kgReference
Gear 5 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
