Tractor · 2008Unverified
Versatile 375
Versatile 375 — Model year 2008-20112012-2017 · 303 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
303 hp
Max power
267.7 kW
Weight
14288 kg
Hover a source tag to verify
Overview
ManufacturerVersatile (a part of Rostselmash)Reference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockoptionalReference
Steeringhydrostatic powerReference
Single dry caliper brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 11.9L 6-cyl dieselReference
Fuel tank1135.5 LReference
Engine279.6 kWReference
Drawbar (tested)217.1 kWReference
Cummins QSX11.9Reference
turbocharged and air-to-air aftercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement11.9 LReference
Bore/Stroke130 x 150 mmReference
EmissionsInterim Tier IVReference
Power279.6 kWReference
Maximum Power309.5 kWReference
Rated RPM2100Reference
Torque1966.2 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Max power267.7 kWReference
Max power217.1 kWReference
Transmission
12-speed partiallly synchronizedReference
16-speed full power shiftReference
Typepartiallly synchronizedReference
Gears12 forward and 4 reverseReference
TransmissionCaterpillar TA19Reference
Typefull power shiftReference
Gears16 forward and 4 reverseReference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)223.7 kWReference
PTO (tested)267.7 kWReference
Typeclosed center load sensing (CCLS)Reference
Pressure200.0 barReference
Valves4 to 6Reference
Pump flow200.6 lpmReference
Pump flow401.2 lpmReference
Rear TypeIII/IVNReference
Rear PTO Type1000 (1.75)Reference
Power at rated PTO speed225.9 kWReference
Dimensions
Wheelbase342 cmReference
Weight14288 kgReference
Front tire710/70R38Reference
Rear tire710/70R38Reference
Ag front710/70R38Reference
Ag rear710/70R38Reference
14288 kgReference
Max Drawbar2721 kgReference
Max Drawbar4082 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Charging volts12Reference
Batteries3Reference
Battery CCA950Reference
Battery volts12Reference
Capacities
Max capacity17010 kgReference
Test results
Diesel 16-speed 4WDSeptember 5 - 11, 2013Link: OCED Tractor Test 2066 fileReference
PTO performanceReference
Fuel use74.9 l/hourReference
Fuel use75.3 l/hourReference
Drawbar performanceReference
Fuel use76.1 l/hourReference
Gear 6 used for power test.Reference
Max pull17217 kgReference
Gear 2 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
