Tractor · 1972Unverified
Versatile 700
Versatile 700 — Model year 1972-19751976-1977 · 210 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
210 hp
Weight
7711 kg
Hover a source tag to verify
Overview
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with available heater and air-conditioning.Reference
Engine
Cummins 9.1L 8-cyl dieselReference
Engine156.6 kWReference
Cummins V-555-C210Reference
dieselReference
8-cylinderReference
liquid-cooled V8Reference
Displacement9.1 LReference
Bore/Stroke117 x 105 mmReference
Power156.6 kWReference
Air cleanerdual dry elementReference
Pre-heatingether injectionReference
Rated RPM2850Reference
Starter volts12Reference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutch355.6mm ceramic discReference
Three gears, plus reverse, in four ranges.Reference
Capacities
Fuel643.5 LReference
PTO & Hydraulics
Hydraulic system70.4 LReference
Typeopen centerReference
Capacity70.4 LReference
Pressure137.9 barReference
Valves3Reference
Pump flow90.8 lpmReference
Steering flow90.8 lpmReference
Steering press.124.1 barReference
Dimensions
Wheelbase330 cmReference
Weight7711 kgReference
Front tire24.5x32Reference
Rear tire24.5x32Reference
Ag front24.5x32Reference
Ag rear24.5x32Reference
Ag front18.4x38Reference
Ag front20.8x38Reference
Ag front30.5x32Reference
Ag rear18.4x38Reference
Ag rear20.8x38Reference
Ag rear30.5x32Reference
Length642 cmReference
Height (exhaust)330 cmReference
700 Serial Numbers
1972070077Reference
1973070601Reference
1974700 5010001Reference
1975700 3010401Reference
1976700 76 011501Reference
1977700 77 013001Reference
Final700 77 013250Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps58Reference
Batteries2Reference
Battery volts12Reference
Battery AH204Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
