Tractor · 1978Unverified
Versatile 855
Versatile 855 — 3 Series · 212 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
212 hp
Weight
9140 kg
Hover a source tag to verify
Overview
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Original price was $85,000 in 1983Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine186.4 kWReference
Cummins NT-855-C250Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power186.4 kWReference
Air cleanerdual dry element with precleanerReference
Compression14.1:1Reference
Rated RPM2100Reference
Idle RPM1000-2300Reference
Torque1152.6 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity44.5 LReference
Oil capacity33.1 LReference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutch355.6mm ceramic discReference
Oil capacity20.3 LReference
Three gears, plus reverse, in four ranges.Reference
PTO & Hydraulics
PTO (claimed)158.1 kWReference
Hydraulic system79.5 LReference
Typeopen centerReference
Capacity79.5 LReference
Pressure155.1 barReference
Valves4Reference
Pump flow89.3 lpmReference
Steering flow98.8 lpmReference
Rear TypeIIIReference
Controlposition and depth controlReference
Rear lift (at ends)8287 kgReference
Rear lift (at 24"/610mm)5611 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Capacities
Fuel700.2 LReference
Dimensions
Wheelbase330 cmReference
Weight9140 kgReference
Front tire20.8-38Reference
Rear tire20.8-38Reference
Ag front20.8-38Reference
Ag rear20.8-38Reference
Length642 cmReference
Height (cab)321 cmReference
Max weight12700 kgReference
855 Serial Numbers
Location:Serial number plate on the cab door post.Reference
1978855 78 150501Reference
1979855 79 150751Reference
1980855 80 151151Reference
1981855 81 151401Reference
1982855 82 151601Reference
1983855 83 151801Reference
Final855 83 151975Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps75Reference
Batteries2Reference
Battery CCA900Reference
Battery volts12Reference
Battery Group80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
