Tractor · 1978Unverified
Versatile 875
Versatile 875 — 3 Series · 248 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
248 hp
Max power
164.2 kW
Weight
11625 kg
Hover a source tag to verify
Overview
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Original price was $110,000 in 1984Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine208.8 kWReference
Drawbar (claimed)187.9 kWReference
Drawbar (tested)167.1 kWReference
Cummins NT-855-A280Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power208.8 kWReference
Air cleanerdual dry element with precleanerReference
Compression14.1:1Reference
Rated RPM2100Reference
Idle RPM1000-2300Reference
Torque1247.5 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity44.5 LReference
Oil capacity33.1 LReference
Power at rated engine speed185.0 kWReference
Max power164.2 kWReference
Power at rated engine speed184.3 kWReference
Max power162.2 kWReference
Power at rated engine speed188.4 kWReference
Max power167.1 kWReference
Transmission
12-speed gearReference
TransmissionVersatileReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutch355.6mm ceramic discReference
Oil capacity20.3 LReference
Three gears, plus reverse, in four ranges.Reference
PTO & Hydraulics
PTO (tested)188.4 kWReference
Hydraulic system79.5 LReference
Typeopen centerReference
Capacity79.5 LReference
Pressure155.1 barReference
Valves4Reference
Pump flow89.3 lpmReference
Steering flow98.8 lpmReference
Rear TypeIIIReference
Controlposition and depth controlReference
Rear lift (at ends)8287 kgReference
Rear lift (at 24"/610mm)5611 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Capacities
Fuel700.2 LReference
Dimensions
Wheelbase330 cmReference
Weight11625 kgReference
Front tire20.8x38Reference
Rear tire20.8x38Reference
Ag front20.8x38Reference
Ag rear20.8x38Reference
Ag front24.5x32Reference
Ag front30.5x32Reference
Ag front18.4x38Reference
Ag rear24.5x32Reference
Ag rear30.5x32Reference
Ag rear18.4x38Reference
Length642 cmReference
Width362 cmReference
Height321 cmReference
Max weight13381 kgReference
875 Serial Numbers
Location:Serial number plate on the cab door post.Reference
1978875 78 052501Reference
1979875 79 053201Reference
1980875 80 054301Reference
1981875 81 055501Reference
1982875 82 056601Reference
1983875 83 057801Reference
1984875 84 059025Reference
Final875 84 059617Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps75Reference
Batteries2Reference
Battery CCA900Reference
Battery volts12Reference
Battery Group80Reference
Test results
NTTL 1279: diesel 12-speed 4WDReference
NTTL 1332: diesel 12-speed 4WDReference
NTTL 1483: diesel 12-speed 4WDReference
Diesel 12-speed 4WDJune 3 - 8, 1978Link: Nebraska Tractor Test 1279 fileReference
PTO performanceReference
Fuel use60.9 l/hourReference
Drawbar performanceReference
Fuel use61.3 l/hourReference
Gear 2-3 used for power test.Reference
Max pull11093 kgReference
Gear 1-3 used for pull test.Reference
Diesel 12-speed 4WDOctober 30 - 13, 1979Link: Nebraska Tractor Test 1332 fileReference
Fuel use58.3 l/hourReference
Fuel use57.5 l/hourReference
Max pull12154 kgReference
Gear 1-2 used for pull test.Reference
Diesel 12-speed 4WDMay 31 - June 10, 1983Link: Nebraska Tractor Test 1483 fileReference
Fuel use63.6 l/hourReference
Fuel use55.6 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
