Tractor · 1985Unverified
Versatile 876
Versatile 876 — 6 Series · 246 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
246 hp
Max power
170.3 kW
Weight
18100 to 24900 pounds
Hover a source tag to verify
Overview
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Original price was $93,000 in 1993Reference
Power take-off (PTO) was optional with the power shift transmission on the 876 and not available with the manual shift.Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Final drivesinboard planetary (row-crop axle)Reference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 10.0L 6-cyl dieselReference
Engine208.8 kWReference
Drawbar (tested)170.3 kWReference
Cummins LT10-A280Reference
aftercooled turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement10.0 LReference
Bore/Stroke125 x 136 mmReference
Power208.8 kWReference
Air cleanerdual dry elementReference
Pre-heatingether injectionReference
Pre-heatingblock heaterReference
Compression16:1Reference
Rated RPM2100Reference
Torque1213.6 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity26.5 LReference
Coolant capacity53.5 LReference
Max power170.3 kWReference
Transmission
12-speed constant meshReference
12-speed full power shiftReference
TransmissionVersatileReference
Typeconstant meshReference
Gears12 forward and 4 reverseReference
Clutch356mm dry discReference
Oil capacity20.3 LReference
Typefull power shiftReference
Gears12 forward and 2 reverseReference
Clutch228mm wet discReference
Oil capacity17.0 LReference
PTO & Hydraulics
PTO (claimed)183.4 kWReference
Hydraulic system57.9 LReference
Typeclosed center load sensingReference
Capacity57.9 LReference
Pressure155.1 barReference
Valves4 to 5Reference
Pump flow95.4 lpmReference
Steering flow98.0 lpmReference
Steering press.158.6 barReference
Rear TypeIVN/IIIReference
Controlposition controlReference
Rear lift (at 24"/610mm)4677 kgReference
Rear lift (at 24"/610mm)5913 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Capacities
Fuel931.1 LReference
Max capacity13381 kgReference
Dimensions
Wheelbase330 cmReference
Weight18100 to 24900 poundsReference
Front tire20.8x38Reference
Rear tire20.8x38Reference
Ag front20.8x38Reference
Ag rear20.8x38Reference
Ag front18.4x38Reference
Ag front18.4x42Reference
Ag front24.5x32Reference
Ag front30.5x32Reference
Ag rear18.4x38Reference
Ag rear18.4x42Reference
Ag rear24.5x32Reference
Ag rear30.5x32Reference
Length660 cmReference
Ground clearance40 cmReference
Front axle101 mmReference
Front axleFlangeReference
Bar rear axle101 mmReference
Flange rear axleReference
Shipping8210 kgReference
Operating11294 kgReference
Steering wheel260 cmReference
876 Serial Numbers
Location:Serial number plate on the cab door post.Reference
1985876 85 223035Reference
1986876 86 270331Reference
1987876 87 ------Reference
1988876 88 330100Reference
1989876 89 D430197Reference
1990876 90 D450167Reference
1991876 91 D475041Reference
1992876 92 D485111Reference
1993876 93 D930000Reference
Final876 93 D931179Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Batteries4Reference
Battery CCA625Reference
Battery volts12Reference
Versatile 876 Height
Cab317 cmReference
Exhaust332 cmReference
Test results
Diesel manual 4WDMay 21 - 29, 1985Link: Nebraska Tractor Test 1569 fileReference
Drawbar performanceReference
Fuel use51.5 l/hourReference
Gear 2-3 used for power test.Reference
Max pull12566 kgReference
Gear 1-2 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
