Tractor · 1978Unverified
Versatile 935
Versatile 935 — 3 Series · 330 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
330 hp
Weight
9072 kg
Hover a source tag to verify
Overview
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Original price was $112,700 in 1982Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 14.8L 8-cyl dieselReference
Fuel tank700.2 LReference
Engine246.1 kWReference
Cummins VT-903-C330Reference
turbocharged dieselReference
8-cylinderReference
liquid-cooled V8Reference
Displacement14.8 LReference
Bore/Stroke140 x 121 mmReference
Power246.1 kWReference
Air cleanerdual dry element with precleanerReference
Compression15.5:1Reference
Rated RPM2400Reference
Idle RPM1000-2910Reference
Torque1149.9 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity51.1 LReference
Oil capacity24.6 LReference
Transmission
12-speed gearReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutch355.6mm ceramic discReference
Oil capacity20.3 LReference
Three gears, plus reverse, in four ranges.Reference
PTO & Hydraulics
Typeopen centerReference
Valves4Reference
Pump flow93.1 lpmReference
Steering flow110.5 lpmReference
Rear TypeIIIReference
Controlposition and depth controlReference
Rear lift (at ends)8287 kgReference
Rear lift (at 24"/610mm)5611 kgReference
Dimensions
Wheelbase330 cmReference
Weight9072 kgReference
Front tire20.8-38Reference
Rear tire20.8-38Reference
Ag front20.8-38Reference
Ag rear20.8-38Reference
Length642 cmReference
Height (cab)321 cmReference
Max weight14742 kgReference
935 Serial Numbers
Location:Serial number plate on the cab door post.Reference
1978935 78 071700Reference
1979935 79 071901Reference
1980935 80 072101Reference
1981935 81 072451Reference
1982935 82 072701Reference
Final935 82 072839Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps75Reference
Batteries2Reference
Battery CCA900Reference
Battery volts12Reference
Battery Group80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
