Tractor · 1978Unverified
Volvo 2200
Volvo 2200 — Utility tractor · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
2945 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Utility tractorReference
Total built1819Reference
Two-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Volvo BM cab standard with heater.Reference
Variants
22002WDReference
22044WDReference
Engine
Volvo 3.9L 4-cyl dieselReference
Fuel tank87.8 LReference
Engine41.8 kWReference
Volvo D39TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power41.8 kWReference
Fuel systemdirect injectionReference
Pre-heatingthermostartReference
Compression16:1Reference
Rated RPM2200Reference
Torque218.0 NmReference
Torque RPM1400Reference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
8-speed synchromeshReference
16-speed two-speed power shiftReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Clutch279.4mm dry discReference
Four gears in two ranges, plus reverse.Reference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Optional hydraulic power shift adds an additional high-low shift to the base eight-speed transmission.Reference
PTO & Hydraulics
PTO (claimed)34.3 kWReference
Pressure172.0 barReference
Valves2Reference
Pump flow45.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1850 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1940Reference
Dimensions
Wheelbase216 cmReference
Weight2945 kgReference
Front tire7.50-16Reference
Rear tire13.6-38Reference
Ag front7.50-16Reference
Ag rear13.6-38Reference
Ag front10.00-16Reference
Ag rear16.9-34Reference
Length370 cmReference
Width186 cmReference
Height255 cmReference
Ground clearance42 cmReference
Front tread141 cmReference
Front tread138/141/157/169/180/189 cmReference
Rear tread141/151/162/171/182/192 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Batteries2Reference
Battery volts12Reference
Battery AH140Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
