Tractor · 1979Unverified
Volvo 2204
Volvo 2204 — Utility tractor · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
3400 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Utility tractorReference
Total built320Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Volvo BM cab standard with heater.Reference
Variants
22002WDReference
22044WDReference
Engine
Volvo 3.9L 4-cyl dieselReference
Fuel tank87.8 LReference
Engine41.8 kWReference
Volvo D39TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power41.8 kWReference
Fuel systemdirect injectionReference
Pre-heatingthermostartReference
Compression16:1Reference
Rated RPM2200Reference
Torque218.0 NmReference
Torque RPM1400Reference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
8-speed synchromeshReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Clutch279.4mm dry discReference
Four gears in two ranges, plus reverse.Reference
PTO & Hydraulics
PTO (claimed)34.3 kWReference
Pressure172.0 barReference
Valves2Reference
Pump flow45.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1850 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1940Reference
Dimensions
Wheelbase216 cmReference
Weight3400 kgReference
Front tire9.5-24.8Reference
Rear tire13.6-36.6Reference
Ag front9.5-24.8Reference
Ag rear13.6-36.6Reference
Ag front11.2-24Reference
Ag rear13.6-38Reference
Length370 cmReference
Height254 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Batteries2Reference
Battery volts12Reference
Battery AH140Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
