Tractor · 1959Unverified
Volvo 470
Volvo 470 · 79 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
79 hp
Weight
3360 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Total built3695Reference
Two-wheel driveReference
Manual steeringReference
Mechanical shoe brakesReference
Open operator station. Four-post ROPS and cab available.Reference
Engine
Bolinder 5.0L 4-cyl dieselReference
Fuel tank110.1 LReference
Engine (gross)58.9 kWReference
Engine (net)54.4 kWReference
Bolinder 1114 TRReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke111 x 130 mmReference
Power (net)54.4 kWReference
Power (gross)58.9 kWReference
Fuel systemdirect injectionReference
Compression16.5:1Reference
Rated RPM1800Reference
Starter volts12Reference
Oil capacity12.0 LReference
Coolant capacity19.0 LReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Clutch355.6mm dry discReference
Oil capacity55.0 LReference
PTO & Hydraulics
Rear TypeIReference
Rear lift1300 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1500Reference
Dimensions
Wheelbase217 cmReference
Weight3360 kgReference
Front tire7.50-18Reference
Rear tire16.9/14-34Reference
Ag front7.50-18Reference
Ag rear16.9/14-34Reference
Length344 cmReference
Width189 cmReference
Height (hood)164 cmReference
Height (exhaust)249 cmReference
Ballasted weight4970 kgReference
Ground clearance42 cmReference
Front tread133 cmReference
Rear tread151 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
