Backhoe Loader · Unverified
Volvo BL70
Volvo BL70 — Backhoe loader tractor · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
8606 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Backhoe loader tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Independent wet disc brakesReference
Engine
Volvo 4.0L 4-cyl dieselReference
Engine67.1 kWReference
Volvo D4DReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Power67.1 kWReference
Compression19:1Reference
Rated RPM2200Reference
Torque390.0 NmReference
Torque RPM1500Reference
Oil capacity14.0 LReference
Coolant capacity18.9 LReference
Transmission
4-speedReference
Gears4 forward and reverseReference
Power shift from forward to reverse, synchronized shifts between gears.Reference
Capacities
Fuel120.0 LReference
PTO & Hydraulics
Hydraulic system135.1 LReference
Typeclosed centerReference
Capacity135.1 LReference
Pressure249.9 barReference
Total flow159.0 lpmReference
Dimensions
Wheelbase218 cmReference
Weight8606 kgReference
Front tire12.5/80-18Reference
Rear tire19.5Lx24Reference
Industrial front12.5/80-18Reference
Industrial rear19.5Lx24Reference
Industrial front21Lx24Reference
Length734 cmReference
Width236 cmReference
Height287 cmReference
Height368 cmReference
Operating weight8606 kgReference
Ground clearance30 cmReference
Backhoe & Loader
Dig depth439 cmReference
Electrical
Charging systemalternatorReference
Charging amps95Reference
Battery CCA690Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Volvo Standard Backhoe
Backhoe typeVolvo Standard BackhoeReference
Digging depth439 cmReference
Reach from pivot581 cmReference
Bucket force6031 kgReference
Dipperstick force3953 kgReference
Volvo Extendible Backhoe
Backhoe typeVolvo Extendible BackhoeReference
Digging depth546 cmReference
Reach from pivot678 cmReference
Loading height441 cmReference
Bucket force6031 kgReference
Dipperstick force2903 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
