Industrial Tractor · 1966Unverified
Volvo LM 422
Volvo LM 422 — LM Series · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
4200 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Wheel LoaderReference
Two-wheel driveReference
Disc brakesReference
Cab standard with heater.Reference
Engine
Perkins 2.5L 3-cyl dieselReference
Engine (gross)35.0 kWReference
Perkins D913Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power (gross)35.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2250Reference
Torque164.1 NmReference
Torque RPM1350Reference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and reverseReference
Clutch304.5mm dry discReference
Dimensions
Wheelbase210 cmReference
Weight4200 kgReference
Front tire13-28Reference
Rear tire7.50-18Reference
Industrial front13-28Reference
Industrial rear7.50-18Reference
Length502 cmReference
Height (cab)241 cmReference
Ground clearance34 cmReference
Front tread167 cmReference
Rear tread152 cmReference
Volvo LM 422 attachments
front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
