The Volvo T15 Krabat is a tractor with a rating of 21 hp, positioning it at the lower end of its class in terms of power output. It was produced from 1956 to 1957. The tractor is equipped with a 4-cylinder petrol liquid-cooled engine and two-wheel drive with a 4-speed gearbox. Its operating weight is listed as 1349 kg, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
1349 kg
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
21 hp
Recorded weight
1349 kg
Transmissions
4-speed gear
Production years
1956-1957
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Two-wheel driveReference
Open operator station.Reference
Engine
Volvo 1.4L 4-cyl gasolineReference
Engine19.8 kWReference
Volvo B14Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke75 x 80 mmReference
Power19.8 kWReference
Compression7.3:1Reference
Rated RPM2500Reference
Operating RPM1700-2500Reference
Oil capacity3.8 LReference
Coolant capacity8.0 LReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)15.4 kWReference
Hydraulic system25.0 LReference
Typeopen centerReference
Capacity25.0 LReference
Pump flow19.7 lpmReference
Rear PTO Type540 (1.375)Reference
Engine RPM555@1700Reference
Capacities
Fuel40.1 LReference
Dimensions
Wheelbase191 cmReference
Weight1349 kgReference
Front tire4.00-19Reference
Rear tire10-28Reference
Ag front4.00-19Reference
Ag rear10-28Reference
Length296 cmReference
Width169 cmReference
Clearance (front axle)44 cmReference
Clearance (rear axle)39 cmReference
Front tread123/145 cmReference
Rear tread134 to 194 cmReference
Steering wheel134 cmReference
Volvo T15 Height
Hood124 cmReference
Exhaust196 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
