The Volvo T22 is a compact tractor with a rated power of 22 hp, distinguishing it from larger models in its class. Production of the Volvo T22 took place from 1947 to 1952. The tractor is equipped with a 4-cylinder liquid-cooled engine and two-wheel drive, and features a 5-speed gearbox. Its listed weight is 1255 kg, suitable for applications involving approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1255 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
22 hp
Recorded weight
1255 kg
Transmissions
5-speed gear
Production years
1947-1952
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Standard-tread tractorReference
Two-wheel driveReference
Open operator station.Reference
Engine
Volvo 2.0L 4-cyl keroseneReference
Fuel tank45.0 LReference
Aux. fuel3.8 LReference
Engine16.4 kWReference
VolvoReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke84 x 90 mmReference
Power16.4 kWReference
Rated RPM1500Reference
Starter volts6Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Engine RPM540@1400Reference
Dimensions
Wheelbase169 cmReference
Weight1255 kgReference
Front tire5.00-15Reference
Rear tire10-28Reference
Ag front5.00-15Reference
Ag rear10-28Reference
Length250 cmReference
Width167 cmReference
Ballasted weight1900 kgReference
Front tread119/136 cmReference
Rear tread119 to 189 cmReference
Steering wheel163 cmReference
Volvo T22 Height
Hood132 cmReference
Exhaust185 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
