Tractor · 1949Unverified
Volvo T31
Volvo T31 — T30 Series · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Weight
2295 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Standard-tread tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
T31kerosene standardReference
T32gasoline standardReference
T33kerosene row-cropReference
T34gasoline row-cropReference
Engine
Volvo 3.5L 4-cyl keroseneReference
Fuel tank60.2 LReference
Aux. fuel3.8 LReference
Engine26.8 kWReference
Volvo D4FReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke100 x 110 mmReference
Power26.8 kWReference
Rated RPM1500Reference
Starter volts6Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Engine RPM540@1500Reference
Dimensions
Wheelbase196 cmReference
Weight2295 kgReference
Front tire6.00-19Reference
Rear tire13-30Reference
Ag front6.00-19Reference
Ag rear13-30Reference
Length311 cmReference
Width183 cmReference
Ballasted weight3440 kgReference
Ground clearance41 cmReference
Front tread125/144 cmReference
Rear tread144 to 194 cmReference
Steering wheel182 cmReference
Volvo T31 Height
Hood155 cmReference
Exhaust210 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
