Tractor · 1952Unverified
Volvo T34
Volvo T34 — T30 Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
2280 kg
Hover a source tag to verify
Overview
ManufacturerVolvoReference
Row-Crop tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
T31kerosene standardReference
T32gasoline standardReference
T33kerosene row-cropReference
T34gasoline row-cropReference
Engine
Volvo 3.5L 4-cyl keroseneReference
Fuel tank60.2 LReference
Engine33.6 kWReference
Volvo D4BReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke100 x 110 mmReference
Power33.6 kWReference
Rated RPM1500Reference
Starter volts6Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Engine RPM540@1500Reference
Dimensions
Wheelbase200 cmReference
Weight2280 kgReference
Front tire6.00-19Reference
Rear tire11-38Reference
Ag front6.00-19Reference
Ag rear11-38Reference
Length314 cmReference
Width168 cmReference
Height217 cmReference
Clearance (front axle)53 cmReference
Clearance (drawbar)45 cmReference
Front tread128 to 170 cmReference
Rear tread134 to 194 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
