Tractor · 1964Unverified

Volvo T400

Name: Volvo T400
Brand: Volvo

Volvo T400 · 47 hp. Reference specifications; pending source verification.

The Volvo T400 is a compact tractor model with a rated output of 47 hp, produced from 1964 to 1969. It features a 3-cylinder diesel liquid-cooled engine driving through four-wheel drive with an 8-speed gearbox, and has a listed weight of 1890 kg. The T400 is capable of handling jobs of up to 200 acres. Its specifications are detailed below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

1890 kg

Catalogue coverage

Variants represented

Richest spec table

52 rows

Recorded power

47 hp

Recorded weight

1890 kg

Transmissions

8-speed gear

Production years

1964-1969

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerVolvoReference

Total built22589Reference

Two- or four-wheel driveReference

SteeringmechanicalReference

Four-post ROPS.Reference

Engine

Perkins 2.5L 3-cyl dieselReference

Engine35.0 kWReference

Perkins D913Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke91 x 127 mmReference

Power35.0 kWReference

Compression18.5:1Reference

Rated RPM2250Reference

Torque164.1 NmReference

Torque RPM1350Reference

Starter volts12Reference

Oil capacity6.0 LReference

Coolant capacity8.0 LReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Oil capacity42.0 LReference

Four gears, plus reverse, in two ranges.Reference

Capacities

Fuel45.0 LReference

PTO & Hydraulics

Hydraulic system23.1 LReference

Capacity23.1 LReference

Pump flow35.0 lpmReference

Rear TypeII/IReference

Rear lift1050 kgReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1800Reference

Dimensions

Wheelbase210 cmReference

Weight1890 kgReference

Front tire6.00-16Reference

Rear tire12.4/11-32Reference

Ag front6.00-16Reference

Ag rear12.4/11-32Reference

Ag front12.4/11-36Reference

Ag front14.9/13-28Reference

Length313 cmReference

Width167 cmReference

Height (hood)135 cmReference

Height (ROPS)219 cmReference

Operating weight1890 kgReference

Ballasted weight2940 kgReference

Ground clearance43 cmReference

Front tread121/138 cmReference

Front tread121 to 179 cmReference

Rear tread135 to 177 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
