Tractor · 1955Unverified
Wagner TR-6
Wagner TR-6 — TR Series · 105 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
5760 kg
Hover a source tag to verify
Overview
ManufacturerWagnerReference
Four-wheel Drive (4WD) tractorReference
Built in Portland, Oregon, USAReference
Four-wheel driveReference
Final drivesplanetaryReference
Steeringhydraulic powerReference
Hydraulic brakesReference
Open operator station. Cab optional.Reference
Engine
Cummins 6.6L 6-cyl dieselReference
Engine78.3 kWReference
Cummins JF-6Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke105 x 127 mmReference
Power78.3 kWReference
Rated RPM2200Reference
Torque379.7 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity28.4 LReference
Transmission
8-speedReference
TransmissionFuller R-46Reference
Gears8 forward and 2 reverseReference
Capacities
Fuel212.0 LReference
PTO & Hydraulics
Hydraulic system113.6 LReference
Capacity113.6 LReference
Pump flow41.6 lpmReference
Steering flow41.6 lpmReference
Dimensions
Wheelbase266 cmReference
Weight5760 kgReference
Front tire13.00x26Reference
Rear tire13.00x26Reference
Standard tires (ag)Front: 13.00x26. Rear: 13.00x26Reference
Length482 cmReference
Width205 cmReference
Height203 cmReference
Height (cab)261 cmReference
Ground clearance40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
