Tractor · 1961Unverified
Wagner WA-14
Wagner WA-14 — WA Series · 220 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
220 hp
Weight
10432 kg
Hover a source tag to verify
Overview
ManufacturerWagnerReference
Four-wheel Drive (4WD) tractorReference
Built in Portland, Oregon, USAReference
Four-wheel driveReference
Final drivesplanetaryReference
Steeringhydraulic powerReference
Pneumatic brakesReference
Open operator station. Cab optional.Reference
Engine
Cummins 12.2L 6-cyl dieselReference
Engine164.1 kWReference
Cummins NH-220Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement12.2 LReference
Bore/Stroke130 x 152 mmReference
Power164.1 kWReference
Rated RPM2100Reference
StarterelectricReference
Starter volts24Reference
Coolant capacity51.1 LReference
Transmission
10-speedReference
TransmissionFuller 10-G-1220Reference
Gears10 forward and 2 reverseReference
Capacities
Fuel567.8 LReference
PTO & Hydraulics
Hydraulic system302.8 LReference
Capacity302.8 LReference
Pump flow238.5 lpmReference
Dimensions
Wheelbase345 cmReference
Weight10432 kgReference
Front tire18-26Reference
Rear tire18-26Reference
Standard tires (ag)Front: 18-26. Rear: 18-26Reference
Length624 cmReference
Width269 cmReference
Height243 cmReference
Height (cab)322 cmReference
Ground clearance40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
