The Waltanna 4-200 is a tractor with a rated power output of approximately 200 hp, positioning it at the higher end of its class. It was manufactured from 1978 to 1981 and features a 6-cylinder turbocharged diesel engine, which is liquid-cooled, and is paired with a four-wheel drive system and a 14-speed gearbox. The tractor has an operating weight of 12100 kg. Its suitable working area ranges from 600 to 1,500 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
200 hp
Weight
12100 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
200 hp
Recorded weight
12100 kg
Transmissions
14-speed gear
Production years
1978-1981
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerWaltannaReference
Four-wheel Drive (4WD) tractorReference
Built in Tarrington, Victoria, AustraliaReference
Four-wheel driveReference
Articulated power steeringReference
Cab standard with air-conditioning.Reference
Engine
Caterpillar 10.5L 6-cyl dieselReference
Engine149.1 kWReference
Caterpillar 3306TReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement10.5 LReference
Bore/Stroke121 x 152 mmReference
Power149.1 kWReference
Rated RPM2200Reference
Operating RPM1500-2200Reference
Torque691.6 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
14-speed gearReference
TransmissionSpicerReference
TypegearReference
Gears14 forward and 2 reverseReference
PTO & Hydraulics
Hydraulic system135.1 LReference
Capacity135.1 LReference
Pump flow115.1 lpmReference
Dimensions
Weight12100 kgReference
Front tire24.5x32Reference
Rear tire24.5x32Reference
Ag front24.5x32Reference
Ag rear24.5x32Reference
Length606 cmReference
Width408 cmReference
Height (exhaust)325 cmReference
Front tread261 cmReference
Rear tread261 cmReference
Speeds
With 24.5x32 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
