The Waltanna 4-210 is a tractor model with a rated power output of 210 horsepower, positioning it at the upper end of its class. It was manufactured from 1978 to 1981. The tractor features an 8-cylinder diesel liquid-cooled engine paired with four-wheel drive and a 10-speed gearbox. Its listed operating weight is 8,450 kilograms, making it suitable for operations covering 600–1,500 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
210 hp
Weight
8450 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
210 hp
Recorded weight
8450 kg
Transmissions
10-speed gear
Production years
1978-1981
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerWaltannaReference
Four-wheel Drive (4WD) tractorReference
Built in Tarrington, Victoria, AustraliaReference
Four-wheel driveReference
Articulated power steeringReference
Cab standard with air-conditioning.Reference
Engine
Caterpillar 10.4L 8-cyl dieselReference
Engine156.6 kWReference
Caterpillar 3208Reference
dieselReference
8-cylinderReference
liquid-cooledReference
Displacement10.4 LReference
Bore/Stroke114 x 127 mmReference
Power156.6 kWReference
Rated RPM2800Reference
Operating RPM1400-2800Reference
Torque649.5 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
10-speed gearReference
TransmissionSpicerReference
TypegearReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Hydraulic system65.9 LReference
Capacity65.9 LReference
Pump flow115.1 lpmReference
Dimensions
Weight8450 kgReference
Front tire23.1x30Reference
Rear tire23.1x30Reference
Ag front23.1x30Reference
Ag rear23.1x30Reference
Length564 cmReference
Width248 cmReference
Height (exhaust)325 cmReference
Front tread189 cmReference
Rear tread189 cmReference
Speeds
With 23.1x30 tiresReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
