Tractor · 1978Unverified
Waltanna 4-250
Waltanna 4-250 — 4 Series · 250 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
250 hp
Weight
12100 kg
Hover a source tag to verify
Overview
ManufacturerWaltannaReference
Four-wheel Drive (4WD) tractorReference
Built in Tarrington, Victoria, AustraliaReference
Four-wheel driveReference
Articulated power steeringReference
Cab standard with air-conditioning.Reference
Engine
Caterpillar 10.5L 6-cyl dieselReference
Engine186.4 kWReference
Caterpillar 3306TReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement10.5 LReference
Bore/Stroke121 x 152 mmReference
Power186.4 kWReference
Rated RPM2200Reference
Operating RPM1500-2200Reference
Torque690.2 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
14-speed gearReference
TransmissionSpicerReference
TypegearReference
Gears14 forward and 2 reverseReference
PTO & Hydraulics
Hydraulic system65.9 LReference
Capacity65.9 LReference
Pump flow115.1 lpmReference
Dimensions
Weight12100 kgReference
Front tire23.1x30Reference
Rear tire23.1x30Reference
Ag front23.1x30Reference
Ag rear23.1x30Reference
Length606 cmReference
Width408 cmReference
Height (exhaust)325 cmReference
Front tread261 cmReference
Rear tread261 cmReference
Speeds
With 23.1x30 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
