Tractor · 1981Unverified

Waltanna 44-175

Name: Waltanna 44-175
Brand: Waltanna

Waltanna 44-175 — 44 Series · 175 hp. Reference specifications; pending source verification.

The Waltanna 44-175 is a tractor model with a rated output of 175 hp, categorising it as a high-powered machine in its class. It was manufactured between 1981 and 1984. The tractor is equipped with an 8-cylinder diesel liquid-cooled engine, transmitting power to all four wheels via a 20-speed gearbox. Its weight is listed as 8150 kg, making it suitable for jobs covering approximately 600 to 1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

175 hp

Weight

8150 kg

Catalogue coverage

Variants represented

Richest spec table

43 rows

Recorded power

175 hp

Recorded weight

8150 kg

Transmissions

20-speed gear

Production years

1981-1984

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWaltannaReference

Four-wheel Drive (4WD) tractorReference

Built in Tarrington, Victoria, AustraliaReference

Four-wheel driveReference

Articulated power steeringReference

Hydraulic disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Caterpillar 10.4L 8-cyl dieselReference

Engine130.5 kWReference

Caterpillar 3208Reference

dieselReference

8-cylinderReference

liquid-cooledReference

Displacement10.4 LReference

Bore/Stroke114 x 127 mmReference

Power130.5 kWReference

Rated RPM2800Reference

Operating RPM1400-2800Reference

Torque539.7 NmReference

Torque RPM1400Reference

Starter typeelectricReference

Transmission

20-speed gearReference

TypegearReference

Gears20 forward and 4 reverseReference

Capacities

Fuel786.9 LReference

PTO & Hydraulics

Hydraulic system135.1 LReference

Typeopen centerReference

Typeclosed centerReference

Capacity135.1 LReference

Pressure137.9 barReference

Valves2Reference

Pump flow126.0 lpmReference

Dimensions

Weight8150 kgReference

Front tire23.1x30Reference

Rear tire23.1x30Reference

Ag front23.1x30Reference

Ag rear23.1x30Reference

Length564 cmReference

Width248 cmReference

Height (exhaust)305 cmReference

Front tread189 cmReference

Rear tread189 cmReference

Speeds

With 23.1x30 tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
