Tractor · 1981Unverified
Waltanna 44-300
Waltanna 44-300 — 44 Series · 300 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
300 hp
Weight
12500 kg
Hover a source tag to verify
Overview
ManufacturerWaltannaReference
Four-wheel Drive (4WD) tractorReference
Built in Tarrington, Victoria, AustraliaReference
Four-wheel driveReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine223.7 kWReference
Cummins NTC-300Reference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power223.7 kWReference
Rated RPM2100Reference
Operating RPM1500-2100Reference
Torque1356.0 NmReference
Torque RPM1300Reference
Starter typeelectricReference
Transmission
20-speed gearReference
12-speed full power shiftReference
TypegearReference
Gears20 forward and 4 reverseReference
Typefull power shiftReference
Gears12 forward and 2 reverseReference
Capacities
Fuel786.9 LReference
PTO & Hydraulics
Hydraulic system135.1 LReference
Typeclosed centerReference
Capacity135.1 LReference
Pressure206.8 barReference
Valves3Reference
Pump flow113.6 lpmReference
Dimensions
Weight12500 kgReference
Front tire23.1x34Reference
Rear tire23.1x34Reference
Ag front23.1x34Reference
Ag rear23.1x34Reference
Length606 cmReference
Width420 cmReference
Height (exhaust)325 cmReference
Speeds
With 23.1x34 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
