Tractor · 1948Unverified
Waterloo Manufacturing Company Bronco
Waterloo Manufacturing Company Bronco — Utility tractor · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
602 kg
Hover a source tag to verify
Overview
ManufacturerWaterloo Manufacturing CompanyReference
Utility tractorReference
Built in Waterloo, Ontario, CanadaReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Wisconsin 0.8L 2-cyl gasolineReference
Engine8.4 kWReference
Wisconsin TEReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement0.8 LReference
Bore/Stroke76 x 83 mmReference
Power8.4 kWReference
Fuel systemcarburetorReference
Rated RPM2600Reference
Firing order1-2Reference
Starter typehand crankReference
Starter typeelectricReference
Sparkplug gap0.762 mmReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutch165mm dry discReference
Dimensions
Weight602 kgReference
Front tire4.00-12Reference
Rear tire7-24Reference
Ag front4.00-12Reference
Ag rear7-24Reference
Ag rear8-24Reference
Ground clearance54 cmReference
Front tread91 cmReference
Rear tread86 to 137 cmReference
Bronco Serial Number Location
Serial number plate above steering column.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
