Lawn Tractor · 1987Unverified
Wheel Horse 111-6
Wheel Horse 111-6 — 100 Series · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
181 kg
Hover a source tag to verify
Overview
ManufacturerWheel HorseReference
Riding lawn mowerReference
Built in South Bend, Indiana, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
11HP Briggs & Stratton 399cc 1-cyl gasolineReference
Fuel tank4.7 LReference
Briggs & Stratton 253707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.36 ciReference
Bore/Stroke87 x 67 mmReference
Power8.2 kWReference
Starter volts12Reference
Transmission
5-speed gearReference
TransmissionPeerless 920Reference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Dimensions
Wheelbase118 cmReference
Weight181 kgReference
Front tire4.10/3.50-4Reference
Rear tire16x6.50-8Reference
30" mid-mount mower deckReference
bladeReference
Lawn/turf front4.10/3.50-4Reference
Lawn/turf rear16x6.50-8Reference
Length164 cmReference
Width81 cmReference
111-6 Serial Numbers
Location:Serial number decal on the left side of the Wheel Horse111-6 frame, below the ignition switch. Model codes shown in parentheses.Reference
1987-unknown-Reference
1988-unknown-Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
30" mid-mount mower deckReference
BladeReference
30" Mower deck
Typemid-mount Wheel HorseReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
