Lawn Tractor · 1996Unverified
Wheel Horse 12-32XL
Wheel Horse 12-32XL — XL Series · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
170 kg
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
12HP Briggs & Stratton 465cc 1-cyl gasolineReference
12HP Briggs & Stratton 344cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & Stratton 282707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
The 282707 was used through the 1998 model year, 12-32XL tractor model number 71188.Reference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)8.9 kWReference
Starter volts12Reference
Briggs & Stratton 284707Reference
air-cooledReference
The 284707 was used starting with the 1997 and model year on the 12-32XL.Reference
Briggs & Stratton 219907Reference
The 219907 was used on the 12-32XL beginning in the 2004 model year.Reference
Displacement21 ciReference
Bore/Stroke85 x 57 mmReference
Transmission
5-speed gearReference
TransmissionPeerless MST-205Reference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase119 cmReference
Weight170 kgReference
Front tire13x5.00-6Reference
Rear tire16x6.50-8Reference
32" mid-mount mower deckReference
bladeReference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear16x6.50-8Reference
Length168 cmReference
Width95 cmReference
Height (steering wheel)101 cmReference
Front axleCast-ironReference
12-32XL Serial Numbers
Location:Serial number on top of tractor fender deck, below the seat.Reference
19966900001 (71188)Reference
19977900001 (71188/71189)Reference
19988900001 (71188/71189)Reference
19999900001 (71189)Reference
2000200000001 (71199)Reference
2001210000001 (71199)Reference
2002220000001 (71199)Reference
2003230000001 (71199)Reference
2004240000001 (71199)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery CCA160Reference
Battery volts12Reference
Attachment overview
32" mid-mount mower deckReference
BladeReference
32" Mower deck
Typemid-mount ToroReference
Type1-bladeReference
Cutting width81 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
