Lawn Tractor · 1999Unverified
Wheel Horse 13-32XLE
Wheel Horse 13-32XLE — Lawn tractor · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Lawn tractorReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
13HP Briggs & Stratton 458cc gasolineReference
13HP Briggs & Stratton 344cc gasolineReference
Briggs & Stratton 28M707Reference
gasolineReference
air-cooledReference
Displacement28 ciReference
Power (gross)9.7 kWReference
Air cleanerfoam and paper elementsReference
StarterelectricReference
Starter volts12Reference
SparkplugChampion RC12YCReference
Sparkplug gap0.762 mmReference
Oil capacity1.4 LReference
Briggs & Stratton 21A907Reference
Displacement21 ciReference
Transmission
5-speed gearReference
TransmissionPeerless 205-509Reference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Front PTOindependentReference
ClutchmanualReference
Dimensions
32" mid-mount mower deckReference
13-32XLE Serial Numbers
19999900001 (71209)Reference
2000200000001 (71209)Reference
2001210000001 (71209)Reference
2002220000001 (71209)Reference
2003230000001 (71209)Reference
2004240000001 (71209)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery CCA160Reference
Battery volts12Reference
32" Mower deck
Typemid-mount ToroReference
Cutting width81 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
