Lawn Tractor · 1999Unverified
Wheel Horse 15-38HXL
Wheel Horse 15-38HXL — XL Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
15.5HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & Stratton 28Q777Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power11.6 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-Gear 321-0500Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Wheelbase119 cmReference
Front tire15x6.00-6Reference
Rear tire18x9.50-8Reference
38" mid-mount mower deckReference
bladeReference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear18x9.50-8Reference
Length168 cmReference
15-38HXL Serial Numbers
Location:Serial number decal on the rear fender deck, below the seat.Reference
Electrical
GroundnegativeReference
Battery CCA160Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
BladeReference
38" Mower deck
Typemid-mount ToroReference
Type2-blade with manual liftReference
Cutting width96 cmReference
Overall width114 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
